FEATURES
10 Input Channels
• 8 x Mono Microphone/Line Inputs
• 2 x Stereo Input Channels
Built-in USB/SD MP3 Player & Recorder
• Supports multiple audio formats
• Easy playback and recording functions
Professional Audio Processing
• 3-Band EQ on each channel
• 7-Band Graphic Equalizer on Master Output
• Optimised for live music, bands, DJs, churches and events
Dual AUX Sends & Returns
• Flexible monitoring and effects routing
48V Phantom Power
• Suitable for condenser microphones
High Quality Microphone Preamps
• Ultra-low noise design
• Low distortion
• Wide dynamic range
Compact & Portable Design
• Easy to transport and operate
====================================
SPECIFICATIONS
Maximum Input Level
• Mic: +22dBu
• Line: +20dBu
Maximum Output Level
• Main XLR Output: +28dBu
• Other Outputs: +22dBu
Frequency Response
• 20Hz – 30kHz (±1dB)
Mic CMRR @ 1kHz
• >80dB Typical
THD+N @ +14dBu, 1kHz
• Mic to Mix Output: <0.01%
Crosstalk @ 1kHz
• Fader Shutoff: >80dB
• Mute Shutoff: >82dB
Noise (20Hz – 20kHz)
• Mic Input E.I.N: -122dBu
• Main Mix Fader Unity, Channel Down: <-95dBu
• Main Mix Fader Unity, Channel Unity: <-82dBu
EQ Section
HIGH:
• Shelving ±15dB @ 12kHz
MID:
• Peaking ±15dB @ 2.5kHz
LOW:
• Shelving ±15dB @ 80Hz
Metering
• 3-Colour LED Quasi-Peak Meter
• 12-Segment Master Meter (-30dB to +16dB)
Channel PAD/LINE
• -20dB (MIC Input)
========================================
Ideal for:
• Live Bands
• Churches
• Schools
• Karaoke
• DJs
• Events & Functions
• Home Recording
• Small PA Systems
